35mm² Copper lug contained M6 [Pack of 100]

This 35mm² copper tube crimping lug is designed for secure and efficient electrical connections, featuring a contained palm for enhanced stability. Manufactured from high-purity electrolytic copper exceeding 99.9%, it ensures excellent conductivity. The lug is annealed for optimum ductility, facilitating easy and reliable crimping. Its insulation sleeve form allows for straightforward conductor insertion, while the tin-plated surface prevents oxidation, ensuring long-term durability. With a maximum voltage rating of 11kV and an operating temperature range from -50°C to +150°C, this lug is ideal for various demanding applications.

Technical Specifications

Download Product Technical Data Sheet

• Type: Copper tube crimping lug
• Surface protection: Tinned
• Flange shape: Ring shape
• Connecting angle: 180° (horizontal)
• Material: Copper
• AWG size: 2
• Bolt dimension (metric): 6
• Number of fixing holes: 1
• Nominal cross section: 35 mm²
• Insulated: No
• With sight-hole: No
• Slender flange model: Yes
