Basiccharge EV Charging Pedestal Three Phase Black 2X Type 2 (IEC 62196) Charging Sockets Up To 22kW (32A) Per Socket 1X 63A Three Phase 400V Ac

The Basiccharge EV Charging Pedestal offers a straightforward, cost-effective charging solution perfect for workplaces, public car parks, and commercial locations. Designed with simplicity and durability in mind, this robust pedestal features two Type 2 sockets delivering up to 22kW per socket on a 3-phase 63A 400V AC supply. Its built-in LED amenity lighting, controlled by a photocell, ensures better visibility and safety around the charging bays during low-light conditions.

Future-proof and OCPP 1.6 compliant, the Basiccharge supports plug & charge functionality and allows users to authenticate via smartphone app or RFID card/fob, integrating seamlessly with your preferred back-office management system. With built-in AC overload and fault current protection (RCBO), this steel-constructed pedestal delivers safe, reliable performance designed to withstand tough environments.

Technical Specification

• Download Product Technical Data Sheet

• Housing Material: Steel

• Voltage Type: AC

• Installation Side Connection Model: 3-phase

• Degree of Protection: IP54

• Impact Resistance: IK10

• Frequency: 50/60 Hz

• Open Charge Point Protocol (OCPP) Version: 1.6

• Width: 205 mm

• Height: 1130 mm

• Depth: 205 mm

• Number of Charging Units: 2

• Number of Vehicle Connectors (Type 2): 2

• Max Power per Charging Point: 22 kW

• Max Output Current DC: 32 A

• Suitable for Floor Mounting: Yes

• Suitable for Wall Mounting: No
