BG Sync Generation 2 22kW Socketed EV Wall Charger With WIFI, 4G & RFID Function
excl. VAT
💳 0% APR Finance Available*
Experience fast, secure, and smart EV charging with the BG Sync Generation 2 22kW Socketed Wall Charger. Designed for home, workplace, and fleet service environments, this high-performance charger delivers dynamic charging up to 22kW and includes built-in Wi-Fi, LAN, 4G, and RFID functionality. Perfectly compliant with the UK Electric Vehicles (Smart Charge Points) Regulations 2021, it's the ideal choice for modern electric vehicle owners and operators.
Technical Specifications
-
Download Product Technical Data Sheet
-
Download Product Technical Data Sheet
-
Connectivity Options: Wi-Fi, LAN, 4G, RFID-enabled
-
Smart Charging: Full smart control via the Monta app
-
Dynamic Charging Capacity: 7.4kW (single-phase) / 22kW (three-phase)
-
No Earth Rod Required: Integrated open PEN conductor protection
-
Safety First: Built-in Type A RCD
-
OCPP 1.6J Compatible: Lifetime OTA (over-the-air) firmware updates
-
Charging Interface: Type 2 socket with auto-lock feature
-
Installation: 3-phase side connection model
-
Charger Dimensions:
-
Width: 201 mm
-
Height: 305 mm
-
Depth: 115 mm
-
-
Max Power Output per Charging Unit: 22kW
-
Smart Networking: LAN, Wi-Fi & 4G compatible
Stay connected, compliant, and in control with the BG Sync Generation 2 — the ultimate EV wall charger for future-ready electric mobility.
