FLOODLIGHT SENSOR 20 W 3000 K SYM 100 S BK

The FLOODLIGHT SENSOR 20W 3000K SYM 100 S BK is an innovative outdoor LED floodlight designed to offer bright and efficient illumination for various outdoor applications. Equipped with a flexible motion and daylight sensor, this floodlight is perfect for areas such as building facades, gardens, public spaces, and more. Offering a light output of up to 2400 lumens, it delivers a bright, uniform light distribution, ensuring optimal visibility for any setting.

The integrated motion and daylight sensor comes with adjustable detection range, daylight sensitivity, and hold time, giving you total control over the illumination. The sensor’s 350° pan and 180° tilt provide extensive coverage, making it a reliable choice for both large and small outdoor areas. With a long lifespan of 70,000 hours and an energy-efficient LED design, this floodlight offers an eco-friendly solution that reduces energy consumption by up to 90% compared to halogen alternatives.

Technical Specification

• Download Product Technical Data Sheet

• Light Output: 2400 lumens (max)

• Power Consumption: 20W

• Colour Temperature: 3000K (Warm White)

• Sensor Type: Motion & Daylight sensor with 350° pan and 180° tilt

• Beam Angle: 100° x 100° symmetric light distribution

• Surge Protection: Up to 4 kV (L/N-PE), 2 kV (L-N)

• Energy Efficiency: Up to 90% energy savings compared to halogen floodlights

• Housing Material: Powder-coated aluminum for durability

• Light Diffuser: Frosted tempered glass for reduced glare

• Rated Life Span: 70,000 hours

• Warranty: 5 years

• Mounting: Surface mounting with a 30° adjustable mounting bracket

• Pre-Installed Cable: 1m flexible cable (H05RN-F) with 3 x 1.0 mm² wires

• Power Factor: 0.9 for improved energy efficiency

• Nominal Voltage: 100 - 277 V AC

• Rated Ambient Temperature: -30°C to 50°C

• Impact Resistance (IK rating): IK07

• Control Gear: Electronic ballast

• Connection Type: Screwless terminal

• Protection Class: I (Class 1)

• Colour Rendering Index (CRI/Ra): 80-89

• Light Source Type: LED (non-replaceable)

• Dimming Options: No dimming functionality

• Photobiological Safety (EN 62471): RG1

Application Areas

• Replacement for traditional halogen floodlights

• Ideal for outdoor use in IP65-rated environments

• Suitable for public areas, building facades, and construction sites

• Gardens, balconies, driveways, patios, and other outdoor spaces

Benefits

• Demand-Optimized Illumination: Customizable sensor settings for motion and daylight

• High-Efficiency LED Technology: Save up to 90% on energy costs compared to halogen floodlights

• Durable and Weather-Resistant: Built with a rugged aluminum housing and tempered glass diffuser for outdoor durability

• Long Lifespan: 70,000-hour rated life to reduce maintenance costs

• Flexible Installation: Adjustable mounting bracket and pre-installed 1m cable for easy setup

• 5-Year Warranty: Ensures long-term reliability and peace of mind

Ideal for both residential and commercial settings, the FLOODLIGHT SENSOR 20W 3000K SYM 100 S BK combines advanced motion sensing technology with energy-efficient LED lighting, making it a top choice for anyone seeking reliable, bright, and cost-effective outdoor lighting. Enhance your property’s outdoor lighting while saving on energy bills with this durable, long-lasting LED floodlight.
