Navara Sf Square Multi Cct/Wattage Led Photocell Emergency Fitting

The Navara SF Square Multi CCT/Wattage LED Photocell Emergency Fitting is a versatile, high-performance lighting solution for both commercial and industrial applications. This surface-mounted bulkhead fitting offers exceptional flexibility with its triple CCT (3000K, 4000K, 6000K) and multi-wattage (10W, 14W, 20W) selectable outputs, making it ideal for a wide range of lighting needs. Built to withstand tough environments, this fitting is rated IP65 for dust and moisture protection and IK10 for high impact resistance, ensuring durability and reliability in demanding locations. The Navara SF Square is equipped with advanced features like Emergency and Self-Test Emergency options, providing peace of mind with reliable backup lighting in case of power failure. With a 5-year warranty (3 years on batteries), this fitting is designed for long-lasting performance and energy efficiency, offering up to 102 lumens per circuit watt. Perfect for both wall and ceiling mounting, the Navara SF Square is suitable for use in a variety of applications, including public buildings, retail spaces, and communal areas.

Technical Specification

• Download Product Technical Data Sheet

• Product Name: Navara SF Square Multi CCT/Wattage LED Photocell Emergency Fitting
• Wattage Selectable: 10W, 14W, 20W
• Colour Temperature Selectable: 3000K, 4000K, 6000K
• Light Output: Up to 102 lumens per circuit watt
• CRI: Ra>81
• IP Rating: IP65 (Dust-tight and moisture-resistant)
• Impact Rating: IK10 (High impact resistance)
• Mounting Options: Suitable for wall or ceiling mounting
• Emergency Options: Available in Emergency and Self-Test Emergency versions
• Control Gear: Photocell
• Warranty: 5 years (3 years on batteries)
• Class: Class II
• Operating Temperature: -20°C to +35°C
• Voltage: 220-240V
• Nominal Current: 100-200mA
• Dimensions:
  • Height: 120mm
  • Width: 120mm
  • Depth: 65mm
• Applications: Ideal for retail shops, public buildings, communal areas, corridors, walkways, stairwells, and sports centres

Key Features & Benefits

• Triple CCT & Multi-Wattage Selectable: Offers flexibility to select between 3000K, 4000K, or 6000K colour temperatures and 10W, 14W, or 20W power outputs for customized lighting.
• Energy Efficient: Delivers up to 102 lumens per circuit watt, ensuring excellent light output while minimizing energy consumption.
• High Durability: With an IP65 rating, it’s protected against dust and moisture, while the IK10 impact rating ensures the fitting can withstand challenging environments.
• Emergency Lighting Options: Available with Emergency and Self-Test Emergency versions for reliable backup lighting during power failures.
• Warranty: Comes with a 5-year warranty (3 years on batteries) for peace of mind and long-term reliability.
• Flexible Mounting: Can be mounted on both walls and ceilings, offering versatile installation options for a variety of spaces.

The Navara SF Square Multi CCT/Wattage LED Photocell Emergency Fitting is the perfect choice for any environment where reliability, energy efficiency, and flexibility are essential. Ideal for high-traffic areas, this fitting provides a long-lasting, adaptable solution that can handle any lighting need.
