Staircase ATLANTA

Maximize your space without compromising style or safety with the ATLANTA space-saving staircase. Featuring innovative paddle treads and a compact footprint of just 137 cm in length, this modular staircase is ideal for tight spaces. With adjustable treads and rise options, it supports a wide range of floor-to-floor heights up to 300 cm. The staircase is available in two elegant finishes—painted anthracite multiplex or varnished beech multiplex—allowing you to match your interior perfectly.

Designed for durability and ease of installation, the ATLANTA staircase includes a UV-resistant PVC handrail, powder-coated steel structural elements, and hidden fixings for a clean, semi-gloss finish. Enhance safety with optional features like a second banister, riser bars, or additional vertical balusters to meet UK building regulations.

Technical Specifications:

• Type: Straight flight (Paddle tread)
• Dimensions: Opening length: 137 cm | Opening width: 69 cm | Staircase width: 62 cm
• Floor-to-Floor Height: Up to 300 cm (remove treads for heights below 228 cm)
• Tread Details:
  • Material: Multiplex (anthracite, painted) | Beech multiplex (varnished)
  • Thickness: 35 mm | Width: 58 cm | Going: 11.5 cm
• Tread Rise: Adjustable, 19–25 cm per tread
• Number of Treads/Risers: 11 treads, 12 risers
• Maximum Load: Total load: 400 kg | Point load: 200 kg | Banister horizontal load: 50 kg/m
• Baluster Distance: 20.5 cm | 9 cm with additional baluster configuration
• Handrail Material: PVC
• Use: Indoor, private use in single-family homes

Additional Features:

• Modular design for easy assembly
• UV-resistant, semi-gloss finishes
• Optional safety enhancements: second banister, riser bars, landing banister
