Automatic Crimp Tool

The Wiha Automatic Crimp Tool is a professional solution for precise and reliable processing of wire-end sleeves with and without insulating collars, manufactured in accordance with DIN 46228 and EN 50027 standards. Designed to cover a wide crimping range from 0.08 to 16mm², this versatile tool effectively combines the functionality of two crimping pliers into one compact and efficient solution. Featuring hex crimping technology, the tool eliminates unnecessary cable and wire-end sleeve waste while preventing small sleeves from snagging, ensuring clean and consistent crimp results. The integrated feed system enhances process safety by preventing the plastic collar from being crimped. Elastic, impact-cushioning plastic handles provide excellent comfort and fatigue-free operation during prolonged use. An integrated manual release lever allows the crimping process to be stopped at any time for added control and safety. Manufactured by Wiha, this automatic crimp tool delivers precision, efficiency, and long-lasting performance for professional electrical applications.

Technical Specification

• Download Product Technical Data Sheet

• Tool Type: Automatic Crimp Tool
• Overall Length: 210mm
• Crimping Standards: DIN 46228, EN 50027
• Crimping Range (Single Sleeves): 0.08–16mm²
• Crimping Range (Twin Sleeves): Up to 10mm²
• AWG Range: 28–5 AWG
• Crimping Type: Hex crimping
• Feed System: Prevents crimping of plastic insulating collars
• Handle Type: Elastic, impact-cushioning plastic handles
• Safety Feature: Integrated manual release lever
• Manufacturer Code: 41246
• Stock Code: WHA41246
• Barcode: 4010995412463
• Product Weight: 0.545kg
• Box Quantity: 1
• Minimum Order Quantity: 1
• Dimensions (WxHxD): 135 × 330 × 25mm
• Quality Assurance: ISO9000
