Basiccharge EV Charger Single Phase Black 2X Type 2 (IEC 62196) Charging Sockets Up To 7.4kW (32A) Per Socket 1X 63A 230V AC

The Basiccharge EV Charger is a simplistic, reliable, and affordable charging pedestal designed for both residential and commercial EV charging needs. Featuring two Type 2 (IEC 62196) sockets, this single-phase charger delivers up to 7.4kW (32A) per socket, making it perfect for efficient and fast charging.

Built with user convenience in mind, the Basiccharge includes integrated LED amenity lighting controlled by a photocell, improving visibility of the charging bays and surrounding areas. Its future-proof design is fully OCPP 1.6 compliant, supporting plug & charge, mobile app control, or RFID card/fob operation through any compatible back-office management system.

Safety is a priority with built-in AC overload and fault current protection (RCBO). Network connectivity options include LAN, Wi-Fi, and 4G, ensuring flexible communication and easy remote management. The robust steel housing with IP54 and IK10 ratings guarantees durability for various installation environments.

Technical Specification

• Download Product Technical Data Sheet

• Voltage Type of Supply Voltage: AC

• Installation Side Connection Model: Single phase

• Housing Material: Steel

• Degree of Protection (IP Rating): IP54

• Impact Resistance (IK Rating): IK10

• Frequency: 50/60 Hz

• Open Charge Point Protocol (OCPP) Version: 1.6

• Width: 205 mm

• Depth: 205 mm

• Height: 1130 mm

• Networkable via LAN: Yes

• Networkable via Wi-Fi: Yes

• Radio Standard 4G: Yes

• Number of Socket Outlets Type 2: 2

• Max. Power per Charging Point: 7.4 kW

• Number of Charging Units: 2

• Max. Output Current DC: 32 A

• Floor Mounting: Yes
