Fire Alarm Panel Conventional 2 Zone 380 x 235 x 96mm

The CFP 2 Zone Conventional Fire Alarm Panel is a reliable and user-friendly control solution for small to medium-sized buildings. Designed for ease of installation and operation, it features a clean, compact design with intuitive, colour-coded controls and combined keypad/keyswitch entry. Supporting up to two detector zones and four conventional sounder circuits, this panel is ideal for offices, retail spaces, and residential complexes. Its EN54-4/A2 compliant 1.5A switch mode power supply and extensive range of engineering functions make it a flexible and dependable choice for fire detection systems.

Technical Specification

• Download Product Technical Data Sheet

• Product Type: 2 Zone Conventional Fire Alarm Control Panel

• System Type: Conventional

• Mounting Method: Surface mountable

• Dimensions:

  • Width: 380 mm

  • Height: 235 mm

  • Depth: 96 mm

• Zone Capacity: 2 detector zones

• Sounder Circuits: 4 conventional sounder outputs

• Power Supply: Integral 1.5A EN54-4/A2 compliant switch mode PSU

• Battery Support: Space for 2 x 12V 3.3Ah VRLA batteries

• Current Draw: Low 25mA quiescent current

• Outputs:

  • 2 x On-board relays (Fire and Fault)

  • 2 x Open-collector outputs (Remote and Reset)

• Interface: Colour-coded buttons with combined keypad/keyswitch entry

• Functions:

  • Zone test

  • Coincidence detection

  • Zone delay

  • Non-latching zones

• Design: Flush or surface mountable plastic enclosure – no bezel required

Ensure complete control and confidence in your fire alarm system with the CFP 2 Zone Conventional Panel — engineered for reliability, ease of use, and flexibility in modern safety environments.
